WEATHER SENSOR
FWS500 Multi parameter meteorological sensor Professional grade
Overview
The FRT FWS500 integrated meteorological sensor is a professional-grade device independently developed by our company to measure multiple meteorological elements. It can simultaneously monitor five key parameters: atmospheric temperature, atmospheric humidity, air pressure, wind speed, and wind direction. The sensor features high accuracy, fast response time, strong anti-interference capability, and supports robust serial output. Users can connect the sensor directly to a PC or external equipment for data collection.
Technical Parameters
Measurement | Detection range | Resolution | Accuracy | Measurement principle |
Temperature | -40℃～+85℃ | 0.1℃ | ±0.2℃ | Rtd |
Humidity | 0%~100%Rh | 0.1%Rh | ±2%Rh | Capacitance |
Pressure | 300～1200hpa | 0.1hpa | ±0.3%hpa | Silicon piezoresistive type |
Wind direction | 0～360° | 1° | ±3° | Ultrasonic |
Wind speed | 0～75m/s | 0.1m/s | ±0.3m/s or 3% | Ultrasonic |
Optional functions include GPRS-a01, WiFi-a02, Ethernet-a03, electronic compass-b01, GPS-b02, and battery-d01 | ||||
Size | Length: 140mm Width:140mm Height:310mm |
Weight | About 0.9kg |
Output interface | RS485, RS232, SDI12, 4-20mA, 0-5V optional |
Power supply | 9-30VDC（ Optional solar and 220V power supply） |
Power consumption | <0.4W |
Operation temperature | -40℃～+85℃ |
Relative humidity at work | 0～100%Rh |
Length | Default 3.5m (extendable) |
Degrees of protection provided by enclosure | IP65 |
Apply to | Pole diameter 60-76mm |
Agreement | Supports both ASCII protocol and Modbus RTU protocol simultaneously |
Characteristic
- Maintenance-free system design, easy installation
- Standard communication protocol
- Ultra-low power consumption (0.2W), with RS485 output (RS232 optional)
- Industrial-grade protective casing ensures long-term durability
- Optional built-in modules such as EEPROM, GPRS, and GPS
Applications
FRT FWS Series Integrated Weather Sensor
Products
|
Option |
Temperature |
Humidity |
Air pressure |
Wind |
Rain |
Radiation |
Light |
UV |
|
FWS100 |
✔ |
✔ |
||||||
|
FWS200 |
✔ |
|||||||
|
FWS300 |
✔ |
✔ |
✔ |
|||||
|
FWS400 |
✔ |
✔ |
✔ |
✔ |
||||
|
FWS500 |
✔ |
✔ |
✔ |
✔ |
||||
|
FWS600 |
✔ |
✔ |
✔ |
✔ |
✔ |
|||
|
FWS700 |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
||
|
FWS701 |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
||
|
FWS800 |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
