WEATHER SENSOR
Multi-Element Weather Tracking Sensor
Model Number : FRT FWS800
Overview
The FWS800 is a next-generation, fully integrated Weather Tracking Sensor engineered for professional-grade meteorological monitoring. Designed for precision and reliability, it measures eight key atmospheric parameters including temperature, humidity, barometric pressure, wind speed, wind direction, rainfall, solar radiation, and UV radiation. Its compact design, fast response, and multi-protocol support make it ideal for smart city deployments, environmental research, and industrial weather applications.
Characteristic
- Plug-and-play installation, zero maintenance required
- Supports RS485, RS232, SDI12, and analog output
- Low power draw (<0.4W), efficient for remote use
- Industrial-grade casing, waterproof and dustproof (IP65)
- Optional integration of GPS, GPRS, and BeiDou/COMPASS
Applications
Technical Parameters
General
Measurement | Detection range | Resolution | Accuracy | Measurement principle |
Temperature | -40℃～+85℃ | 0.1℃ | ±0.2℃ | Rtd |
Humidity | 0%~100%Rh | 0.1%Rh | ±2%Rh | Capacitance |
Pressure | 300～1200hpa | 0.1hpa | ±0.3%hpa | Silicon piezoresistive type |
Wind direction | 0～360° | 1° | ±3° | Ultrasonic |
Wind speed | 0～75m/s | 0.1m/s | ±0.3m/s or 3% | Ultrasonic |
Rainfall | 0～5mm/min | 0.1mm/0.01mm | ±5% | Optics / Piezoelectric / Radar |
Radiation | 0 ~ 2000w/m2 | 1w/m2 | ±5%F.S | Photodetector |
UV | 0 ~ 15 level | 1 level | ± 1 level | Photoresistor |
Optional functions include GPRS-a01, WiFi-a02, Ethernet-a03, electronic compass-b01, GPS-b02, and battery-d01 | ||||
| Specification | Description |
|---|---|
| Size | L: 140mm W: 140mm H: 360mm |
| Weight | Approx. 1.1kg |
| Output Interface | RS485, RS232, SDI12, 4-20mA, 0-5V (optional) |
| Power Supply | 9–30VDC (solar or 220V optional) |
| Power Consumption | <0.4W |
| Operating Temperature | -40°C to +85°C |
| Operating Humidity | 0–100% RH |
| Cable Length | Default 3.5m (extendable) |
| Protection Rating | IP65 |
| Mounting | Compatible with pole Ø60–76mm |
| Protocol Compatibility | Supports ASCII & Modbus RTU protocols |
| Typical Applications | Smart cities, weather stations, agriculture, energy sites |
